Turbocharger Installation Guide - Refoneturbo.com

 Turbocharger Installation Guide

Steps to proper turbo installation：
• Change new recommended oil & air filters.
• Change recommended engine oil.
• Pre-oil the turbo oil inlet.
• Change new oil inlet pipes or flush the oil inlet pipes to remove flakes or carbon deposits.
• Ensure oil supply of at least 0.5 kgf/m² or 7 psi within 3 seconds of 1st engine start(if possible, use oil gauge to measure).
• Mount turbine inlet to engine manifold.
• Attach oil inlet pipe to turbo and crank the engine a few times until oil flows out of theturbo oil drain. Then attach the oil drain pipe.
• Connect remaining air piping hose.
• Ensure that all bolts, screws & nuts are tightened.

Pay Attention:

• Do not let foreign objects (screws, bolts, metal fragments, tools)enter ducts.
• Ensure that suitable gasket/metal flange are used for the turbine inlet, oil inlet and oil outlet. Do not use 'glue' gasket.
• Do not handle the turbo via the waste gate actuator rod or boost hose.
After the installation：
• To test, crank the engine for 10 – 15 seconds to prime oil feed without starting the engine.
• Start the engine and let it idle for 3 to 4 minutesto allow for proper inspection of oil, gas and air leakage.
